Sanko Techno ALC Drive ALD Type Stainless Steel Pack ALD-560P30 1 PK

Catalog number: ALD-560P30 Features: ● Drilling, tapping, and installation in one process. ● The use of a special wide-pitch screw thread allows for smooth installation on ALC panels and provides stable, high retention. ● Perfect installation is possible even on corners and edges. Applications: ● For ALC panels, wiring and piping saddle fastening, interior base material installation, lighting fixture installation, guide plate installation, etc. Specifications: ● Embedded depth (mm): 50 ● Maximum tensile load (kN): 0.8 ● Nominal diameter d (mm): 5.0 ● Length (mm): 60 ● Compatible screwdriver: Phillips No. 2 (865, 890 only No. 3) ● Neck length (mm): 60 ● Head height (mm): 2.9 ● Head diameter (mm): 9.6 ● Packed Material/Finish: ● Stainless steel (SUSXM7) Note: ● Maximum tensile load is the value of the ALC panel (100 mm thick) compressive strength Fc = 4N/mm2. ●Please carry out the work directly without drilling pilot holes. ●When using a driver drill, pay attention to the tightening torque (nominal diameter 5: 1.5 to 2.2 N·m). ●Drill holes at least 10 mm deeper than the embedment length.
