Sandvik Spiral Tap CoroTap (780) Nominal size M16 Pitch 1.5mm Thread length 15mm Total length 95mm EX1CPJ2-M16X1.5 1 piece

Catalog number: EX1CPJ2-M16X1.5 Features: ●Highly productive tapping tool. ●High stability due to long tool life and excellent chip control. ●Highly heat-resistant TiN coating ensures long life even in workpieces that tend to trap heat. ●Taps are available for each workpiece material, making selection easy. Applications: ●For blind hole machining. ●Workpiece material: Steel. Specifications: ●Accuracy: 6H ●Nominal size: M16 ●Pitch (mm): 1.5 ●Thread length (mm): 15 ●Total length (mm): 95 ●Shank diameter (mm): 12.5 ●Shank square section (mm): 10 ●Pilot hole diameter (mm): 14.5 ●Number of teeth: 2.5 teeth ●Machining thread: Metric thread ●Surface treatment: TiN coating ●Blade length (mm): 15 ●Number of teeth (pieces): 4 ●Blade diameter (mm): 16 Material/Finish: ●High-speed steel (HSS-E)
