Sugito Handy Micrometer TS-HM-120 1 pc

Catalogue number: TS-HM-120 Features: ●Erect image type with built-in prism. ●Precision scale is standard equipment. ●LED light intensity adjustment and multi-lighting are possible. ●Eyepiece scale makes it easy to read the scale. Applications: ●Inspection of metal parts, printing, semiconductor boards, etc. Specifications: ●Magnification (times): 120 ●Measuring range (mm): 1 ●Minimum scale (mm): 0.01 ●Effective field of view (mm): 1.8 ●Width (mm): 41 ●Height (mm): 225 ●Power supply (V): 4 AAA batteries (sold separately) ●Power supply: 4 AAA batteries (sold separately) ●Precision scale standard equipment Materials/Finish: ●Lens: Glass Set contents/Accessories: ●Cone-shaped diffuse guide (already installed) ●Guide for non-contact observation ●Guide for contact observation
