The wide opening makes cleaning and other maintenance easy.
By using a plunger, it is possible to pump high viscosity materials. Material: Body: Stainless steel (SUS304), O-ring: NBR (nitrile rubber)
Operating pressure: 0.49MPa or less
Material outlet: Bottom port (lower part) / Rc3/8 (standard)
Pressure port: Top port (upper part) / Rc1/4 (standard)
Lid attachment/detachment method: Ferrule clamp type
Buffed finish on the inside and outside
Capacity(L): 1
Inner diameter x height (mm): φ97 x 268
Weight(kg):2.8
TB Series
*Custom-made processing is possible.
