Soft nylon tube, black, 8X6.0, 20M, NB0860-20-B, 1 roll

It has excellent pressure resistance, abrasion resistance, and cold resistance. It can also be used with hot water and heat transfer oil. Convenient cut marks are provided at intervals of approximately 500 mm when cutting the tube. Color: Black Outer diameter (mm): 8 Inner diameter (mm): 6.0 Minimum bending radius (mm): 22 Total length (m): 20 Maximum operating pressure (MPa): 1.3 (20℃ 65%RH) Operating temperature range (℃): For air: -20 to 100 (no freezing) / For water and heat transfer oil: -15 to 90 (no freezing) Fluids used: Air, water (conditions apply), thermal oil (conditions apply) Wall thickness (mm): 1 Tube outer diameter (φD) (mm): φ8 Tube inner diameter (φD) (mm): φ6 Minimum mounting radius (mm): 40 Maximum operating pressure: 1.3MPa (at 20℃ 65%RH) Vacuum pressure used: -100kPa Operating temperature range: -15 to 90°C (water, heat transfer oil, no freezing), -20 to 100°C (air, no freezing) Made in an ISO9001 certified factory Made in an ISO14001 certified factory Material/Finish: Nylon (PA12) Caution: Do not apply loads such as tension, twisting, or extreme bending to the tube. This may cause the tube to collapse, burst, or come loose. Do not rub or tangle the tube so as to avoid scratching it. This may cause the tube to burst. The tube's bursting pressure decreases as the temperature rises, so be sure to understand the operating pressure and ensure that you have a sufficient safety margin. Use the tube with a minimum bending radius or greater. When piping the tube, allow sufficient margin to take into account changes in length, etc. Country of Origin: Japan Code number: 378-1500
