Chukoh Flow PTFE Tube AWG-19 10m AWG-19 1 roll

Catalog number: AWG-19 Features: ●Excellent heat resistance, non-stickiness, high electrical insulation, chemical resistance, and slipperiness. Applications: ●For transferring chemicals such as acids and alkalis. ●For automotive parts. ●For semiconductor manufacturing equipment. Specifications: ●Color: Milky white ●Inner diameter (mm): 0.96 ●Outer diameter (mm): 1.56 ●Total length (m): 10 ●Minimum bending radius (mm): 6 ●Operating pressure (MPa): 2.0 ●Operating temperature range (℃): -40 to 260 ●Compatible fluids: Most acids and alkalis ●Operating temperature range: -50 to 260℃ ●American wire gauge specifications Material/Finish: ●Fluoropolymer (PTFE) Note: ●The physical properties in the table are not guaranteed values.
