Chiyoda silencer brass CSB type R1/8 CSB-01 1 piece

Catalogue number: CSB-01 Features: ●Compact design allows installation in tight spaces. Specifications: ●Volume reduction (dB): 20 or more ●Effective cross-sectional area (mm2): 19 ●Connection diameter: R1/8 ●Total length (mm): 23.5 ●Operating pressure (MPa): 1 ●Operating temperature (℃): 1.6-150 ●Operating fluid: Air ●Processing air flow rate (m3/min): 1.2 ●Operating pressure: 1MPa ●Fluid temperature: 5-150℃ ●Maximum temperature range: 1.6-150℃ ●Guaranteed pressure resistance: 2MPa Materials/Finish: ●Body: Brass ●Element: Sintered brass
