Catalog number: B4-M5SC-O Features: ●Tubes can be removed in three dimensions. ●The main body is made of metal. ●Flow rate can be adjusted smoothly. ●One-touch attachment and detachment without the need for tools. ●Lock structure prevents damage to the tube. Applications: ●Various air piping. Specifications: ●Connection port size: M5 x 0.8 ●Applicable tube outer diameter D (mm): 4 ●Fluid used: Compressed air ●Operating temperature range: -5 to 60°C (no freezing) ●Operating pressure: 0.05 to 0.7 MPa ●Meter-out type Materials/Finish: ●Main body: Brass ●Resin parts: Polyacetal ●Seal rubber: Nitrile rubber (NBR)
