Chiyoda Hose Nipple 10mm R3/8 H6.5-3M 1 pc

Catalogue number: H6.5-3M Features: ● Tightened with a cap nut, it is more reliable than tightening with a hose band, etc. ● Designed to make the most of the air flow rate inside the hose. Specifications: ● Connection diameter D: R3/8 ● Hexagonal side (mm) H1: 19 ● Hexagonal side (mm) H2: 16 ● Type: Hose nipple ● Fluid used: Air, water ● Compatible tube outer diameter x inner diameter (mm): 10 x 6.5 ● Fluid temperature (℃): -5 to 60℃ (air), 5 to 40℃ (water) ● Operating pressure: 1MPa ● Sealed (R threaded section) Material/Finish: ● Body: Brass
