Tecrock Dial Tension Gauge Measurement range 30-300mN DTN-30 1 pc

Catalog number: DTN-30 Features: ● Instantaneous and easy measurement of small forces such as tensile and compressive forces. ● Effective for measuring the measuring force of dial gauges, the spring force of precision springs, and keyboard pressing force. Applications: ● Determining the contact force of microswitches, relays, valves, etc. Specifications: ● Maximum allowable load (N): 0.3 ● Width (mm): 47 ● Depth (mm): 19 ● Height (mm): 100 ● Measurement range (mN): 30-300 ● Minimum graduation (mN): 10 ● Indication error: ±0.5 graduations ● Return error: 0.2 graduations
