Toyox Pressure-resistant braided hose for factory equipment piping (environmental product) Toyo Bio Pro Hose Inner diameter 19 mm x outer diameter 26 mm Length 20 m TBP-19-20 TBP-19-20 1 roll
Catalog number: TBP-19-20 Features: * A pressure-resistant braided hose made from natural resource-derived materials with consideration for protecting the global environment. * The outer tube of this pressure-resistant braided hose uses a biomass plasticizer. * This product is certified to have a biomass content of 15%. * This pressure-resistant braided hose is effective in reducing greenhouse gas emissions. * Can be used as a multi-purpose hose for water, oil, chemicals, air, etc. * As a pressure-resistant braided hose, it has the same performance as our Toyoron hose. Uses: ●For industrial and factory equipment piping (water, oil, chemicals, air) Specifications: ●Length (m): 20 ●Inner diameter (mm): 19 ●Outer diameter (mm): 26 ●Operating pressure (MPa): 0-1.0 (23°C), 0-0.6 (60°C) ●Allowable bending radius (mm or more): 150 ●Operating fluid: Water (industrial water), chemicals, mineral oil, animal and vegetable oil, powder, air ●Operating temperature range (°C): -5 to 60 Material/Finish: ●Soft polyvinyl chloride Caution: ●Operating fluids are water, air, oil, chemicals, and powder, but please check in advance if using with oil, chemicals, or powder. ●Do not use with fuel oil (heavy oil, light oil, kerosene, gasoline, etc.) or solvents. ●Do not use for drinking or food applications. ●Use within the operating temperature and pressure ranges. ●Do not use for negative pressure applications.
