Toyox High pressure hose for water, oil, chemicals and air Toyosignal hose Inner diameter 19mm x outer diameter 26mm Length 20m TSG-19-20 TSG-19-20 1 roll

Catalog number: TSG-19-20 Features: ● [High pressure-resistant blade hose] A pressure-resistant blade hose that can be used with various fluids such as water, oil, chemicals, and air. ● [Prevents trouble] Compared to conventional blade hoses, it has high pressure resistance and is less likely to puncture. ● [Long-lasting] Excellent oil resistance means the hose does not harden easily and maintains its flexibility. ● [Flexibility] Flexible and easy to insert into fittings. ● [Improved maintenance] "Lined" and "arrow markings" allow you to check twists during piping and the direction of the fluid. ● [Legal compliance] Compliant with RoHS2 revised regulations for safety and peace of mind. Uses: ●For factory equipment piping and various machine piping (water, oil, chemicals, air, etc.) Specifications: ●Length (m): 20 ●Inner diameter (mm): 19 ●Outer diameter (mm): 26 ●Operating pressure (MPa): 0-1.0 ●Allowable bending radius (mm or more): 95 ●Operating fluid: Water (industrial water), chemicals, mineral oil, animal and vegetable oil, powder, air ●Operating temperature range: -5 to 60°C ●Color: Light gray/with transparent lines Material/Finish: ●Main material: Soft polyvinyl chloride (PVC) ●Reinforcement: Polyester thread Caution: ●Do not use for drinking, food, or medical purposes. ●Use hose nipples that are suitable for the hose size. Do not use nipples with scratches or rust on the surface. ●The life of a hose is greatly affected by the physical properties of the fluid, temperature, flow rate, and frequency of pressurization and decompression. ●If any abnormality or signs of abnormality are found during start-up inspection or regular inspection, immediately discontinue use and repair or replace with a new hose. ●We recommend using our special hose fittings and hose clamps. Tighten the hose clamps as necessary.
