Catalog number: HPT-15-5 Features: ● [Oil-resistant hose] A pressure-resistant braided hose that is more oil-resistant and less likely to harden than general PVC hoses. A multi-purpose pressure-resistant braided hose that can be used with a variety of fluids, including not only oil but also water, chemicals, and air. ● [Long-lasting] Compared to conventional PVC braided hoses, it has the best oil resistance and is less likely to harden. (Compared to our PVC hoses) ● [Transparency] Good transparency allows you to check the fluid for peace of mind. ● [Flexibility] Flexible and easy to insert into fittings. ● [Legal compliance] Compliant with RoHS2 revised regulations for safety and peace of mind. Uses: ● For factory equipment piping and various machines (oil, water, chemicals, air, etc.) Specifications: ● Length (m): 5 ● Inner diameter (mm): 15 ● Outer diameter (mm): 22 ● Operating pressure (MPa): 1.0 (23°C), 0.8 (70°C) ● Allowable bending radius (mm or more): 95 ● Fluids used: mineral oil, animal and vegetable oil, water (industrial water), chemicals, powder, air ● Operating temperature range: -5 to 70°C ● Color: Natural transparent / Image line + blue warp thread included Material / Finish: ● Main material: Soft polyvinyl chloride (PVC) ● Reinforcement material: Polyester thread Caution: ● Do not use for drinking, food, or medical purposes. ● Use hose nipples that are suitable for the hose size. Do not use nipples with scratches or rust on the surface. ● The life of the hose is greatly affected by the physical properties of the fluid, temperature, flow rate, and frequency of pressurization and depressurization. ●If any abnormality or signs of abnormality are found during start-up or regular inspections, immediately discontinue use and repair or replace with a new hose. ●We recommend using our dedicated hose fittings and hose clamps. Tighten hose clamps as necessary.
