NAC Quick Coupling S/P Type Steel Male Thread Mounting Double Open/Close Type CSP06S 1 pc

Catalog number: CSP06S Features: *The automatic valve closes the passage at the same time as separation, preventing fluid loss and air mixing. Specifications: *Fluids used: air, hydraulic oil, etc. *Maximum operating pressure (MPa): 4.5 *Compatible connection size (inch): R3/4 *Maximum impact pressure (MPa): 6.5 *Operating temperature range: -20 to 80°C *Double-way opening and closing type *Double valve Material/Finish: *Body: Steel *Seal rubber: Nitrile rubber (NBR) Note: *Please specify as the seal material will vary depending on the fluid.
