NAC Quick Coupling TL Type Stainless Steel Male Thread Mounting Plug R1/4 CTL02PF3 1 pc

Catalog number: CTL02PF3 Features: ● A through-type without a valve mechanism, suitable for fluids with low pressure loss and high viscosity. Specifications: ● Fluids used: air, water, hydraulic oil, etc. ● Maximum operating pressure (MPa): 7.5 ● Compatible hose size (inch): 1 1/4 ● Compatible connection size (inch): R1/4 ● Maximum impact pressure (MPa): 10.0 ● Operating temperature range: -20 to 180°C ● Valveless Material/Finish: ● Body: Stainless steel (SUS304) Caution: ● Please note that as the size increases, the pressure resistance decreases.
