NAC Quick Coupling TL Type Stainless Steel Female Thread Mounting Plug Rc2 CTL16PM3 1 pc

Catalog number: CTL16PM3 Features: ● A through-type without a valve mechanism, with little pressure loss and suitable for highly viscous fluids. Specifications: ● Fluids used: air, water, hydraulic oil, etc. ● Maximum operating pressure (MPa): 2.0 ● Compatible connection size (inch): Rc2 ● Maximum impact pressure (MPa): 3.0 ● Operating temperature range: -20 to 180°C ● Valveless Material/Finish: ● Body: Stainless steel (SUS304) Caution: ● Please note that as the size increases, the pressure resistance decreases.
