Nichifu Environmentally Friendly Insulated Crimp Terminal R Type (100P) TMEX 2-4S-YEL 1 PK

Catalog number: TMEX 2-4S-YEL Features: ●The insulation coating is pre-installed in the terminal tube. ●Insulation shape: The TME type has a wire insertion guide (funnel-shaped) inside the insulation coating. ●The core wire can be smoothly inserted into the tube along the guide with the coating stripped without twisting. Applications: ●For connecting stranded wires of soft steel. Specifications: ●Wire confinement range Stranded wire (mm2): 0.3 to 1.65 ●Wire confinement range AWG: 16 to 14 ●Color: Yellow ●Maximum operating temperature (℃): 125 ●Rated voltage (V): 600 ●Not compatible with solid wires ●Operating temperature range: -40℃ to 120℃ ●Complies with RoHS10 substances Materials/Finish: ●Terminal: Oxygen-free copper (electrolytic tin plating) ●Sleeve: Oxygen-free copper tube (electrolytic tin plating) ●Insulation: Polyvinyl chloride Caution: ●For copper wires only. ●Use within the wire confinement range. ●Please use the appropriate crimping tool specified by our company.
