Hakko Super Flexible Fluorine Tube Clear Blue 8 x 12 20m E-SJ-8X12-CBU-20 1 roll

Catalog number: E-SJ-8X12-CBU-20 Features: ●Laminated structure makes it less likely to break and more flexible than commercially available fluorotubes. ●The fluororesin of the inner layer has excellent chemical resistance and complies with the Food Sanitation Act. Applications: ●Transport piping for chemicals, food, oil, cosmetics, medical equipment, organic solvents, etc. Specifications: ●Color: Clear blue ●Inner diameter (mm): 8 ●Outer diameter (mm): 12 ●Total length (m): 20 ●Minimum bending radius (mm): 50 ●Operating pressure (MPa): 20℃: 0-0.6 80℃: 0-0.2 ●Operating temperature range (℃): -20-80 ●Compatible fluids: acetone, methyl ethyl ketone, ethyl acetate ●Allowable bending radius (at 20℃) (mm): 50 ●Operating temperature range: -20-80℃ Materials/Finish: ●Outer layer: Urethane-based elastomer ●Inner layer: 4-fluorinated fluororesin
