Hammer S series all stainless steel swivel urethane wheel (roller bearing) 100mm with stopper 313S-UB100 1 piece

Catalog number: 313S-UB100 Features: ● All-stainless steel casters with excellent corrosion and water resistance. Applications: ● For carts and equipment used in environments where rust and corrosion are unacceptable, such as food factories, stores, and offices. Specifications: ● Wheel diameter D (mm): 100 ● Type: swivel type (with side stopper) ● Permissible load (daN): 100 ● Permissible load (kgf): 102 ● Wheel width (mm): 32 ● Mounting height H (mm): 132 ● Mounting seat A (mm): 90 ● Mounting seat B (mm): 90 ● Mounting pitch X (mm): 68-71 ● Mounting pitch Y (mm): 68-71 ● Mounting hole diameter P (mm): 11 ● Eccentricity E (mm): 35 ● Turning radius (mm): 86 ● Plate type ● With side SP ● Wheel fixing method: Nut Material/Finish: ● Metal fittings: Stainless steel ● Wheels: Urethane Note: ● 315S-UB50, 65, 75 are side stopper types, 315S-UB100, 125, 150 are front stoppers.
