Hiltline Check Valve G1/4 Stainless Steel KH-14SS 1 pc

Catalog number: KH-14SS Features: ● Made of highly durable SUS303, it has a significantly longer life than plastic hoses. ● Screw-type design provides significantly improved retention strength compared to plastic coolant hoses. ● High retention strength means the hose shape will not change due to high-pressure coolant, machine vibration, or interference from cutting chips. Applications: ● For cooling the tip of tools during cutting and grinding processes. ● Can also be used with air. Specifications: Maximum working fluid pressure (kg/cm2): 5Mpa Total length (mm): 39 Thread diameter (mm): G1/4 (stainless steel) Maximum working pressure (MPa): 5 Suitable fluids: Acetone, ammonia water, drinking water, ethanol, ethyl ether, gasoline, nitric acid, vegetable oil, sodium hydroxide, petroleum, cutting oil, kerosene, trichloroethylene, toluene, benzene Flow rate (L/min): 60 Inner diameter (mm): 1/4 Product name: Check valve G1/4 Stainless steel Length (mm): 39 Nominal size: 1/4 Usable temperature: -30°C to +100°C Material/Finish: SUS303 Note: The maximum working pressure and maximum working flow rate data are for 1/4 systems with a hose inner diameter of φ5.8 and 1/2 systems with a round nozzle tip diameter of φ6.5. The chemical resistance of the suitable fluid indicates the chemical resistance of the material itself and does not guarantee the chemical resistance of this product.
