Victor Scroll Chuck SC85F 3 inch 3 jaws Integrated jaw SC85F 1 unit

Catalog number: SC85F Features: ●The jaws are heat-treated for high hardness, making them extremely durable. ●The inner and outer jaws can be used interchangeably, making them extremely economical. Applications: ●Mainly for lathe machining. Specifications: ●Chuck outer diameter (mm): 87 ●Gripping force (kN): 10 ●External diameter gripping (mm): 2-71 (86) ●Internal diameter gripping (mm): 22-59 (74) ●Jaw shape: Integrated jaws (inner and outer jaws) ●Mounting section conforms to JIS ●Rear mounting with 3 bolts for all sizes ●Integrated hard jaw type (with inner and outer jaws) ●Rear mounting Material/Finish: ●Body: Cast iron (FC300) ●Hard jaws: SCM415 Set contents/Accessories: ●Operation handle x 1 ●Mounting bolts: M6 x 30 x 3 Caution: ●It is possible to grip up to the inside of the ( ), but this is not recommended.
