Catalog number: 542430 Features: ●Two components with top load and intelligent functions (expand, fold, knot) to match the base material, etc. ●Optimal tightening of the plug. (Tightening feeling, depending on the type of screw) ●Appropriate plug length for quick installation without deep drilling. ●Thin plug rim reduces sinking into the hole. ●The jagged cut shape reduces co-rotation when tightening the screw. Applications: ●For concrete, brick, ALC, gypsum board, natural stone, plywood, concrete block, and extruded cement board. Specifications: ●Nominal diameter (mm): 5 ●Length (mm): 25 ●Drilling depth (mm): 35 ●Maximum tensile load (kN): 2.31 ●Maximum tensile load (kN) concrete: 2.31 ●Maximum tensile load (kN) ALC: 0.66 ●Counterbore diameter (mm): 5 ●Compatible screws (mm): 3-4 ●Compatible screws: wood screws, tapping screws ●Gypsum board thickness: 9.5mm or more Material/Finish: ●Grey part: Polyamide PA6 (Nylon 6) ●Red part: Polypropylene (PP) Note: ●The type of screw used will vary depending on the type and thickness of the base material.
