Fischer Exterior Insulation Anchor Thermax 16/170 M12 A4 051543 1 Box

Catalog number: 051543 Features: ● A system that can penetrate through plaster or mortar to the insulation material and fasten. ● The bolt material is A4 (equivalent to SUS316) and has high corrosion resistance. ● The thermal barrier (black head) minimizes heat loss. ● Fixation with FIS-VS adhesive injection anchor, which is easy to install, allows for professional installation with high strength, ease, and in a short time. Applications: ● For concrete, stone, brick, ALC, and hollow walls. Specifications: ●Length (mm): 170 ●Minimum drilling depth (mm): 80 ●Drill diameter (mm): 18 ●Minimum penetration depth (mm): 80 ●Drill diameter (mm) concrete: 18 ●Drill diameter (mm) hollow wall base material: 20 ●Set contents: 10 x M16 anchors, 10 x cold protection cones, 10 x sleeves, 3 x bits, 3 x cutting blades, 3 x tubes, 3 x instruction manuals (English) ●Screw-in type ●Boxed ●Fastening for external insulation material Material/Finish: ●Stainless steel + polypropylene (PP) Set contents/Accessories: ●Use with the Fis-vs series.
