Prescale (pressure measurement film) for high pressure HS 1 sheet

It is possible to measure the clamping pressure of the fastening parts, the contact pressure of the rolls, etc. The pressure distribution across the entire measurement surface can be determined at a glance. Measurement range (MPa): 50.00 to 130.0 Type: Mono sheet type Accuracy: ±10% or less (measured by a concentration meter) Width x length: 270mm x 10m How to use: Cut the press scale into the required shape, align film A and film C (one sheet for mono-sheet type), clamp it over the area to be measured and apply pressure to cause it to change color. RoHS2 (EU)2015/863 compliant [About RoHS]
