Multi-timer SPDT 24 → 230 V ac/dc 17.5mm 102-6134 1pc

UL Certified L Series - Selectable Control Relay The L-Series Relay range of timer, control and three-phase relays incorporates the latest technology and offers a wide range of user selectable features. 17.5 mm DIN rail housing Microprocessor based True RMS monitoring Isolated auxiliary power (24 → 230 V ac/dc) 1 x 8 A SPDT relay output Green LED indicates power status Quantity: 1 Monitoring Applications: Current Power supply voltage: 24 → 230V ac/dc Contact configuration: SPDT Electric Phase: 1 Current sensitivity: overcurrent, low current Minimum detectable current: 1A Maximum detectable current: 10A Delay time: 0.1 -> 30 seconds Frequency detection range: 48 → 63 Hz Terminal Type: Screw RoHS Compliance Status: Compliant Code number: 102-6134
