Mahr Large Millimetre (4338100) 1000A 1 piece

Catalogue number: 1000A Features: ●Large, high-contrast dial. ●The measuring spindle is mounted on a high-precision ball guide to minimize hysteresis. ●The measuring spindle is insensitive to lateral forces (side play). ●The measuring spindle can be retracted either by the cable release screw or by the lift knob. ●Maximum sensitivity and accuracy are ensured by the excellent travel performance and the use of precision gears and pinions. Applications: ●For tests requiring the measurement of large numbers of serial parts. Specifications: ●Manufacturer code: 4338100 ●Scale specifications: 100-0-100 ●Mounting shaft diameter (mm): 28 ●Measuring force (N): 1.9 ± 0.3 ●Measuring range (μm): ± 120 ●Minimum display (μm): 1 ●Adjustable tolerance markers ●Lockable fine adjustment screw ●Shock-resistant travel ●Both mounting shank and measuring spindle are made of hardened stainless steel ●Box-type protective housing ●Constant measuring force ●Spindle type Set contents/accessories: ●Cable release ●Case
