Yamawa Solid Die D M7X0.5 25 diameter D2-M7X0.5-25 1 piece

Catalog number: D2-M7X0.5-25 Features: ●Solid die with improved die runout accuracy. ●High-speed tool steel (HSS) is used to achieve stable machining. Applications: ●Workpiece: Iron, light metal. ●For male thread machining. Specifications: ●Nominal size: M7 ●Pitch (mm): 0.5 ●Outer diameter (mm): 25 ●Thickness (mm): 9 ●Machined thread: Metric thread ●Accuracy: Grade 2 ●Number of chip holes: 4 ●Number of engagement teeth: 2.5 teeth ●Surface treatment: Non-coated Material/Finish: ●High-speed tool steel (HSS)
