Yamawa Carbide Hand Tap for Ultra-High Hardness Steel UH-CT P4 M10X1.5 5P UH-CT-M10X1.5 1 piece

Catalog number: UH-CT-M10X1.5 Features: ●Ideal for tapping SKD materials and pre-hardened steels with HRC of 55 to 60 (Max 61). ●Uses ultra-fine grain carbide alloy with excellent wear resistance and impact resistance. ●Improves the runout accuracy of the entire tap and the roundness of the shank. Applications: ●Cutting material: Tempered steel. Specifications: ●Accuracy: P4 ●Nominal size: M10 ●Pitch (mm): 1.5 ●Thread length (mm): 24 ●Total length (mm): 75 ●Shank diameter (mm): 8.5 ●Shank square section (mm): 6.5 ●Pilot hole diameter (mm): 8.60 ●Machined thread: Metric thread ●Surface treatment: TiALN coating ●Number of teeth: 5 teeth ●Tap grade: P grade Material/Finish: ●Ultra-fine grain carbide alloy (HF)
