YUEI Plate-type Swivel Low-floor Caster Phenol Wheel diameter 65mm H-type CAL-UHG type Mounting dimensions 78 x 78 CAL-UHG-65PB 1 pc

Catalogue number: CAL-UHG-65PB Features: ● Heavy-duty caster with extremely low mounting height. ● Maintains smooth rotation even under heavy load. ● Prevents wheel deformation due to long-term heavy load. Applications: ● Heavy-duty caster with extremely low mounting height for installing equipment, etc. Specifications: ● Wheel diameter D (mm): 65 ● Type: Swivel ● Allowable load (daN): 500 ● Allowable load (kgf): 510 ● Wheel width (mm): 48 ● Mounting height H (mm): 89 ● Mounting seat A (mm): 100 ● Mounting seat B (mm): 100 ● Mounting pitch X (mm): 78 ● Mounting pitch Y (mm): 78 ● Mounting hole diameter P (mm): 10.5 ● Plate type ● Swivel type ● Ultra-low floor type Materials/Finish: ● Metal fittings: Steel ● Metal fittings surface treatment: Trivalent chromium finish ● Wheels: Phenolic resin
