YUEI Plate type Swivel Caster with Anti-entrapment Cover Urethane Wheel diameter 150mm With stopper PM type PMS-LB type IPC Mounting dimensions 94 x 94 (87 x 87) PMS-150UWBLBRINJ-IPCY 1 pc

Catalog number: PMS-150UWBLBRINJ-IPCY Features: ● By attaching a roll-up cover, your feet will not get caught. Applications: ● For hand trucks and lifters. Specifications: ● Wheel diameter D (mm): 150 ● Type: Free-wheeling (with stopper) ● Allowable load (daN): 300 ● Allowable load (kgf): 306 ● Wheel width (mm): 38 ● Mounting height H (mm): 198 ● Mounting seat A (mm): 120 ● Mounting seat B (mm): 120 ● Mounting pitch X (mm): 87-94 ● Mounting pitch Y (mm): 87-94 ● Mounting hole diameter P (mm): 11 ● With roll-up cover (roll-up cover is 25 mm above the floor) ● Plate type ● With free stopper Materials/Finish: ● Metal fittings: Steel ● Metal fittings surface treatment: Trivalent chromium finish ● Wheels: Copper plate wheel, urethane (with bearings)
