Wireless current sensor PS-3212 101-356 1 unit

Current can be measured easily. Simple design With a wireless current sensor and a PC, tablet, or smartphone, you can measure current anytime. You can connect via Bluetooth or USB. Measurement data can be displayed in an easy-to-understand manner Using the dedicated software (SPARKvue.Capstone), you can graph the change in current over time and compare the measured data. Data logging function allows measurements to be taken away from the experiment site Measurement data is stored in the sensor and can be viewed on a PC or tablet after measurement. Measurement range: ±0.1A/±1.0A (2 ranges). Automatic switching Resolution: 0.02mA (0.1A range) 0.2mA (1.0A range) Input resistance: 0.1Ω or more Maximum sampling rate: 1000Hz (normal measurement) 100kHz (scope mode, FFT) Battery: Rechargeable via USB port Compatible software: SPARKvue and Capstone Data logging available: Yes Data logging time: Approx. 13 days* Connectivity: Bluetooth 4.2 or USB 2.0 (see Air Link's [Compatible Devices]) Size: Approx. W57 x D78 x H24mm Weight: Approx. 60g Accessories: Lead wire (alligator clip), USB cable *Depends on sampling rate, measurement environment, and battery condition. Note: The dedicated software "SPARKvue" or "Capstone" is required. Also, if you want to connect to a PC via Bluetooth, a dedicated adapter is required. Product code: 101-356
