Shichisei Metal Connector NCS-50 Series 15-P P NCS-5015-P 1 pc

Catalog number: NCS-5015-P Features: ●Basic metal connector that can be used for a variety of circuits. ●Robust and simple structure provides mechanical and electrical stability. ●Wiring connection method is soldering. Applications: ●Screw-lock connector. Specifications: ●Wire conductor cross-sectional area (mm2): 3.5 ●Connector shape: P (female) ●Number of contacts: 15 ●Limiting operating voltage (V): 300 ●Withstand voltage (V): 2000 ●Rating: 15A250V ●Limiting operating voltage: 300V Materials/Finish: ●Shell: Zinc alloy, chrome plated ●Insulator: Synthetic resin ●Contacts: Copper alloy, silver plated
