Bottom right Star (pressure gauge) (A-frame vertical type, φ100) Pressure range 0.0 to 6.00 MPa S-41-6MP 1 piece

Catalog number: S-41-6MP Features: ● Case and cover are electrocoated for excellent corrosion resistance. ● Can be used for any of the three major fluids (air, oil, water) of pressure gauges. ● JIS B 7505-1 standard product. Specifications: ● Pressure range (MPa): 0.0 to 6.00 ● Minimum scale (MPa): 0.1 ● Designation: AT3/8 x 100 x 6.00MPa ● Precision: ±1.6% FS ● Case shape: A ● Connection size: G3/8B ● Size (mm): 100 ● Size (mm): 100 Material/Finish: ● Bourdon tube: Brass ● Thread: Brass Note: ● Please check the thread size, thread shape (G thread or R thread), and pressure range (MPa) before ordering.
