Bottom right Star (pressure gauge) (A-frame vertical type, φ50) Pressure range 0.0 to 1.60 MPa S-11-1.6MP 1 piece

Catalog number: S-11-1.6MP Features: ●Small shape, suitable for use in tight spaces. ●Smooth pointer movement allows for smooth measurement. ●Can be used for any of the three major fluids (air, oil, water) of pressure gauges. ●JIS B 7505-1 standard product. Specifications: ●Pressure range (MPa): 0.0 to 1.60 ●Minimum scale (MPa): 0.05 ●Name: AT1/4 x 50 x 1.60MPa ●Accuracy: ±2.5% FS ●Connection size: G1/4B ●Case shape: A ●Size (mm): 50 Material/Finish: ●Bourdon tube: brass ●Stud: brass Note: ●Please check the thread size, thread shape (G thread or R thread), and pressure range (MPa) before ordering.
