Bottom right Star (pressure gauge) (A-frame vertical type, φ60) Pressure range 0.0 to 2.50 MPa S-21-2.5MP 1 piece

Catalog number: S-21-2.5MP Features: ● Case and cover are electrocoated for excellent corrosion resistance. ● Can be used for any of the three major fluids (air, oil, water) of pressure gauges. ● JIS B 7505-1 standard product. Specifications: ● Pressure range (MPa): 0.0 to 2.50 ● Minimum scale (MPa): 0.05 ● Designation: AT1/4 x 60 x 2.50MPa ● Precision: ±1.6% FS ● Case shape: A ● Connection size: G1/4B ● Size (mm): 60 ● Size (mm): 60 Material/Finish: ● Bourdon tube: Brass ● Thread: Brass Note: ● Please check the thread size, thread shape (G thread or R thread), and pressure range (MPa) before ordering.
