Bottom right Star (pressure gauge) (A-frame vertical type, φ75) Pressure range 0.0 to 0.16 MPa S-31-0.16MP 1 piece

Catalog number: S-31-0.16MP Features: ● Case and cover are electrocoated for excellent corrosion resistance. ● Can be used for any of the three major fluids (air, oil, water) of pressure gauges. ● JIS B 7505-1 standard product. Specifications: ● Pressure range (MPa): 0.0 to 0.16 ● Minimum scale (MPa): 0.005 ● Designation: AT3/8 x 75 x 0.16MPa ● Precision: ±1.6% FS ● Case shape: A ● Connection size: G3/8B ● Size (mm): 75 ● Size: 75mm Material/Finish: ● Bourdon tube: brass ● Thread: brass Note: ● Please check the thread size, thread shape (G thread or R thread), and pressure range (MPa) before ordering.
