Bottom right Star (pressure gauge) (A-frame vertical type, φ75) Pressure range 0.0 to 0.25 MPa S-31-0.25MP 1 piece

Catalog number: S-31-0.25MP Features: ●Case and cover are electrocoated for excellent corrosion resistance. ●Can be used for any of the three major fluids (air, oil, water) of pressure gauges. ●JIS B 7505-1 standard product. Specifications: ●Pressure range (MPa): 0.0 to 0.25 ●Minimum scale (MPa): 0.005 ●Name: AT3/8 x 75 x 0.25MPa ●Accuracy: ±1.6% FS ●Case shape: A ●Connection size: G3/8B ●Size (mm): 75 ●Size: 75mm Material/Finish: ●Bourdon tube: brass ●Stud: brass Note: ●Please check the thread size, thread shape (G thread or R thread), and pressure range (MPa) before ordering.
