Bottom right: Stainless steel pressure gauge (A-frame vertical type, φ75) Pressure range 0 to 1.60 MPa G311-261-1.6MP 1 piece

Catalog number: G311-261-1.6MP Features: ● Excellent corrosion resistance because stainless steel is used in the liquid contact parts. ● JIS B 7505-1 standard product. Applications: ● For the pharmaceutical, food, and medical industries. ● Can also be used with high-temperature fluids. Specifications: ● Pressure range (MPa): 0 to 1.60 ● Minimum scale (MPa): 0.050 ● Designation: AT3/8 x 75 x 1.60MPa ● Precision: ±1.6%FS ● Case shape: A ● Connection size: G3/8B ● Size (mm): 75 ● Size (mm): 75 Material/Finish: ● Bourdon tube: Stainless steel (SUS304) ● Stock: Stainless steel (SUS304) Note: ● Please check the thread size, thread shape (G thread or R thread), and pressure range (MPa) before ordering.
