Bottom right: General pressure gauge Pressure range 0-10MPa Connection size R1/4 S-11-R-10MPA 1 piece

Catalog number: S-11-R-10MPA Features: ●Small shape, suitable for use in tight spaces. ●Smooth pointer movement allows for smooth measurement. ●Can be used for any of the three major fluids (air, oil, water) of pressure gauges. ●JIS B 7505-1 standard product. Specifications: ●Pressure range (MPa): 0-10 ●Minimum scale (MPa): 0.5 ●Name: AT*R1/4x50x10MPa ●Accuracy: ±2.5%FS ●Connection size: R1/4 Material/Finish: ●Bourdon tube: Brass ●Stud: Brass Note: ●Please check the thread size, thread shape (G thread or R thread), and pressure range (MPa) before ordering.
