Bottom right: General pressure gauge (A-frame vertical type, φ75) Pressure range 0 to 0.10 MPa G311-211-M-0.1MP 1 pc

Catalog number: G311-211-M-0.1MP Features: ●Excellent durability. ●Can be used for steam. ●JIS B 7505-1 standard product. ●Various performance specifications can be manufactured depending on the purpose of use. Specifications: ●Pressure range (MPa): 0-0.10 ●Minimum scale (MPa): 0.002 ●Name: AMT3/8 x 75 x 0.10MPa ●Accuracy: ±1.6%FS ●Case shape: A ●Connection size: G3/8B ●Size (mm): 75 ●Size: 75mm Material/Finish: ●Bourdon tube: Brass ●Stem: Brass Note: ●Please check the thread size, thread shape (G thread or R thread), and pressure range (MPa) before placing an order.
