Bottom right: General pressure gauge (B frame vertical type, φ100) Pressure range 0.0 to 10.00 MPa G421-211-V-10MP 1 pc

Catalog number: G421-211-V-10MP Features: ●Excellent durability. ●Improved vibration resistance. ●Resistant to fluid pulsation. ●JIS B 7505-1 standard product. ●Various performances can be manufactured depending on the purpose of use. Specifications: ●Pressure range (MPa): 0.0 to 10.00 ●Minimum scale (MPa): 0.200 ●Name: BVT3/8 x 100 x 10.00 MPa ●Accuracy: ±1.6% FS ●Case shape: B ●Connection size: G3/8B ●Size (mm): 100 ●Size (mm): 100 Material/Finish: ●Bourdon tube: Brass ●Stem: Brass Note: ●Please check the thread size, thread shape (G thread or R thread), and pressure range (MPa) before ordering.
