Yamabishi Bolt Slider Stationary Type Large Capacity Type Maximum Current 3A Input Voltage 100V V-130-3 1 Unit

Catalog number: V-130-3 Features: ●Copper wire is wound radially around a toroidal iron core, and a carbon brush with a special distribution slides over it. ●This is a voltage regulator that can continuously change the output voltage from 0V to any voltage without interruption. Applications: ●Adjustment of overvoltage and undervoltage. ●Adjustment of rotation speed. ●Temperature adjustment. Specifications: ●Input voltage (V): 100 ●Output voltage (V): 0-130 ●Maximum current (A): 3 ●Capacity (kVA): 0.3 ●Diameter (mm): 116 ●Height (mm): 138 ●Stationary type ●Large capacity type Caution: ●When using continuously for 4 hours or more, use at 70% or less of the current capacity. ●When using super-continuously (8 hours or more), use at 50% as a guideline. ●When using an output of 100V or more, the allowable current x 100V ÷ output voltage is calculated.
