Catalog number: BN-25T0-10 Features: ●A compact unit that integrates three points of FRL. ●Removes moisture and debris from the air, maintains pressure and supplies lubricating oil. Applications: ●Removes moisture and debris from the air, maintains pressure and supplies lubricating oil. Specifications: ●Filtration accuracy (μm): 5 ●Operating pressure (MPa): 1 ●Processing air flow rate (［［M3］］/min): 1.20 ●Connection port size: Rc3/8 ●Oil storage capacity (［［CM3］］): 50 ●Total length (mm): 203 ●Total width (mm): 75 ●Set pressure (MPa): 0.05 to 0.85 ●Fluid used: Air ●Fluid temperature (℃): 5 to 60 ●Fluid temperature: 5 to 60℃ ●Drain discharge method: Manual (However, 25T0 will automatically discharge when the pressure falls below 0.05MPa) ●Oil used: Turbine oil type 1 (equivalent to ISO VG#32)
