Nippon Seiki FRL unit 8A modular connection type BN25T6-8 1 S

Catalog number: BN25T6-8 Features: ●A modular type unit with air filter, regulator, and lubricator functions connected with special attachments. ●Metal bottle, pressure gauge, and bracket are standard equipment. Specifications: ● Filtration accuracy (μm): 5 ● Operating pressure (MPa): 1 ● Processed air flow rate (［［M3］］/min): 0.8 ● Connection diameter: Rc1/4 ● Oil storage capacity (［［CM3］］): 200 ● Overall length (mm): 213 ● Overall width (mm): 230 ● Set pressure (MPa): 0.05 to 0.85 ● Fluid used: Air ● Fluid temperature (℃): 5 to 60 ● Fluid temperature: 5 to 60℃ ● Drain discharge method: Manual (automatic discharge at a pressure of 0.05MPa) ● Oil used: Type 1 turbine oil (equivalent to ISO VG#32) ● Pressure gauge, bracket included ● Air filter: BN-27T5 ● Regulator: BN-3RT5 ● Lubricator: BN-23T5
