Catalog number: BN-25T5-15 Features: ●A modular type unit with a filter regulator and lubricator function connected with a dedicated attachment. ●A metal bottle is included as standard. ●A pressure gauge and bracket are included as standard. Applications: ●Removes moisture and debris from the air, keeps pressure constant, and mixes in lubricating oil. Specifications: ● Filtration accuracy (μm): 5 ● Operating pressure (MPa): 1 ● Processed air flow rate (［［M3］］/min): 1.5 ● Connection diameter: Rc1/2 ● Oil storage capacity (［［CM3］］): 200 ● Overall length (mm): 244 ● Overall width (mm): 152 ● Set pressure (MPa): 0.05-0.85 ● Fluid used: Air ● Fluid temperature (℃): 5-60 ● Drain discharge method: Manual (automatic discharge when pressure is 0.05MPa or less) ● Oil used: Type 1 turbine oil (equivalent to ISO VG#32) ● Pressure gauge, bracket included ● Regulator with filter: BN-3RT5F ● Lubricator: BN-23T5
