Catalog number: BN-2501-20 Features: ●A compact unit with each FRL unit connected by a nipple. ●Removes moisture and debris from the air, stabilizes pressure, and supplies lubricating oil. Specifications: ●Filtration accuracy (μm): 40 ●Operating pressure (MPa): 1 ●Processing air flow rate (［［M3］］/min): 9.0 ●Connection port size: Rc3/4 ●Oil storage capacity (［［CM3］］): 400 ●Total length (mm): 257 ●Total width (mm): 325 ●Set pressure (MPa): 0.05-0.85 ●Fluid used: Air ●Fluid temperature (℃): 5-60 ●Drain discharge method: Manual ●Oil used: Turbine oil type 1 (equivalent to ISO VG#32) Note: ●Pressure gauge sold separately.
