Catalog number: C22PN STEEL Features: * To prevent incorrect connection, the fitting size and sleeve color for oxygen and fuel gas are different for safety. * The main body is chrome plated for excellent corrosion resistance, and the plug is hardened to improve durability. Applications: * For mounting thin rubber hoses Specifications: * Product name: Oxygen plug * Suitable fluid: Oxygen * Connection size: Inner diameter φ5 * Maximum operating pressure (MPa): 0.7 * Pressure resistance (MPa): 1.0 * Operating temperature range (℃): -20 to +80 Materials/Finish: * Main body: Steel (chrome plated)
