Kasuga Electric power switch BSW230B3 BSW230B3 1 piece

Catalog number: BSW230B3 Features: ●Rainproof type. ●Protection class IP64 (JIS C 0920). ●Complies with the Electrical Appliance and Material Safety Act. Applications: ●Power push button switch ON, OFF. Specifications: ●Button characters: ON, OFF ●Maximum applicable motor capacity: Three-phase 200/220V-3.7kW ●Length (mm): 83 ●Width (mm): 174 ●Height (mm): 74 ●Terminal screw: M5 ●Compatible wire (［［MM2］］): 3.5 ●Terminal screw M5 ●Rating (A): 30 ●On/off type Material/Finish: ●ABS resin (equivalent to 5Y7/1)
