Kasuga Denki assembly terminal block T20C10 T20C10 1 piece

Catalog number: T20C10 Features: ● Terminal block pre-assembled with the required number of poles. ● Terminal cover and name sticker included. Applications: ● As a power supply/relay terminal block. Specifications: ● Color: Black ● Number of poles: 10 ● Length (mm): 143 ● Width (mm): 34 ● Height (mm): 22 ● Type: Self-up ● Rating: 250V-30A ● Rated insulation voltage (V): 250 ● Mounting pitch (mm): 133 x 16 ● Terminal screw M4 ● Commercial frequency withstand voltage: 2000V for 1 minute ● Impulse withstand voltage: 4000V ● Suitable wire: 1.25 to 3.5m [M2] Material/Finish: ● Body: Phenol ● Cover: Polycarbonate
