Kasuga Denki assembly terminal block T30C12 T30C12 1 piece

Catalog number: T30C12 Features: ● Terminal block pre-assembled with the required number of poles. ● Terminal cover and name sticker included. Applications: ● As a power supply/relay terminal block. Specifications: ● Color: Black ● Number of poles: 12 ● Length (mm): 220 ● Width (mm): 45 ● Height (mm): 29 ● Type: For screw-type relay ● Rating: 600V-50A ● Terminal screw M5 ● Commercial frequency withstand voltage: 2500V for 1 minute ● Impulse withstand voltage: 6000V ● Suitable wire: 3.5 to 8m [M2] Material/Finish: ● Body: Phenol ● Cover: Polycarbonate
